MOLEX 50802-8000
Features
-Termination Style: Designed for crimp-style wire termination, where the stripped ends of wires are inserted into the connector's contacts and crimped to secure them in place. This termination method provides a secure electrical connection and strain relief for the wires, preventing accidental disconnection.
-Current Rating and Voltage: The connector is rated for specific current carrying capacities and voltage levels, ensuring compatibility with the electrical requirements of various applications. These ratings are typically specified by the manufacturer.
-Keying and Polarization: To prevent mismating and ensure proper alignment during connection, the Molex 5240 connector may feature keying or polarization features. These ensure that connectors can only be mated in the correct orientation, maintaining electrical integrity and preventing damage.
-Environmental Considerations: Designed to operate reliably in various environmental conditions, including temperature fluctuations, vibration, and mechanical stress. This makes the Molex 5240 connector suitable for use in applications where durability and reliability are critical.
Applications
1.LED Lighting Systems
2.DIY Electronics and Prototyping
3.Telecommunications
4.Medical Devices
Specifications
2.54mm Molex 5240 Type Wire To Wire Connector
Order information:
RHTAYM1-2.54
Pitch:2.54mm
pins:2~12
MH=Male Hosing / FH=Female Hosing / MT=Male Terminal / FT=Female Terminal
Specifications
◆Material: Nylon UL 94V0 (Lead Free)
◆Contact : Phosphor Bronze
◆Finish : Plated Tin or Gold Flash Lead over Nickel
◆Current rating:3A AC,DC
◆Voltage rating:250V AC,DC
◆Temperature range:-35℃~+85℃
◆Insulationresistance:100MΩ/Min.
◆Withstanding voltage:1000V AC/minute
◆Contact resistance:20mΩ/Max.
Technical Documents
Please contact us for more information.
