Micro USB connectors

Micro USB Connectors are engineered for compact electronic devices requiring dependable power and data interfaces. Their design emphasizes terminal precision, contact resistance, insertion cycles, housing strength and connector retention. Optimized internal structures help maintain consistent contact performance and minimize connection failures, supporting reliable integration in mobile devices, portable equipment, embedded systems and other space-constrained electronic applications.

Enlarge

Quick View

CONN PLUG MICRO USB TYPE B Solder : RHTAY35-3

Series Part No:RHTAY35-3

RoHS Compliance:Yes

Download Datasheet:

Write Your Request Full P/N :

QTY:

Features

-Compact Micro USB Type B plug with T3.0 solder terminals, ideal for PCB mounting, portable electronics, and space-constrained designs.
-High mechanical durability and reliable performance, gold-plated contacts ensure stable data transmission and corrosion resistance.
-Easy soldering, compatible with both manual and automated assembly processes, RoHS-compliant and environmentally friendly.
-Suitable for consumer electronics, IoT devices, embedded systems, wearables, and other small form factor applications.

Applications

1.Networking Equipment

2.Robotics

3.Embedded Systems

4.Audio/Video Equipment

Specifications

Material:
Housing:LCP ,UL94V-0 Black.
Contact:Phosphor Bronze,T=0.20±0.01mm.
Front Shell:Stainless Steel,T=0.20±0.01mm.
Back Shell:Stainless Steel,T=0.20±0.01mm.
Clasp:Stainless Steel,T=0.40±0.01mm.
Finishes:
Contacts: Gold flashed,on Contact area.
100u-120u" Tin.Plating, on solder tails.
50u-80u" Nickel,Underplating over all.
Electrical:
Current Rating:1A Max.
Dielectric Withstanding Voltage:
500 VAC far Minute.
Contact Resistance:30mΩ Max.
Insulation Resistance:1000MΩ Min at DC 500V.
Temperature Range:-55°C TO +105°C.

Technical Documents

Please contact us for more information.

X

X
Enlarge

Quick View

CONN PLUG MICRO USB Solder : RHTAY35-5

Series Part No:RHTAY35-5

RoHS Compliance:Yes

Download Datasheet:

Write Your Request Full P/N :

QTY:

Features

-Micro USB solder connector, compact design ensures secure PCB installation and minimal footprint for modern electronic devices.
-High mechanical durability, stable signal integrity, and reliable power connections suitable for repeated plug-in cycles.
-Quick and convenient soldering process, compatible with automated assembly lines or DIY electronics projects.
-Supports a wide range of applications including portable gadgets, IoT modules, embedded systems, and smart wearables.

Applications

1.Security & Surveillance Devices

2.Gaming Devices

3.Energy Monitoring & Control Systems

4.Laboratory Equipment

Specifications

Material:
Housing:LCP E130,UL94V-0 Black
Contact:Brass 5210.
Shell:Stainless Steel,T=0.20±0.03mm.
Plating:
Contact:Plated Gold Flash For Contact Area.
Shell:Nickel Over All (salt spray for 24H).
Shell:Gold Over All (salt spray for 24H).
Electrical:
Operating Temperature:-20°C TO +80°C.
Product Compliant to the request RoHS

Technical Documents

Please contact us for more information.

X

X
Enlarge

Quick View

CONN PLUG MICRO USB TYPE B PCB MID MOUNT : RHTAY36-5M1

Series Part No:RHTAY36-5M1

RoHS Compliance:Yes

Download Datasheet:

Write Your Request Full P/N :

QTY:

Features

-Compact Micro USB Type B PCB mid-mount connector, designed for secure and reliable PCB installation in portable electronics, embedded systems, and small form factor devices.
-Durable gold-plated contacts provide corrosion resistance, stable data transmission, and efficient power delivery for low to medium current applications.
-Easy-to-solder T3.0 terminals compatible with manual, reflow, or wave soldering processes; RoHS-compliant and environmentally friendly.
-Ideal for consumer electronics, IoT devices, wearable technology, industrial embedded systems, and other miniaturized PCB applications.

Applications

1.Industrial Electronics

2.Communication Equipment

3.Networking Devices

4.Portable Electronics

Specifications

Material
Housing:LCP,UL94V-0,Black.
Contact:Copper Alloy.
Shell:SUS 304 T=0.20.
Finish:
Contact:Gold Plating on Contact area.
80u" Sn Plating on solder tail area.
50u" Min.Nickel Under plating over all.
Electrical:
Voltage Rating:30VAC RMS.
Current Rating:2.0A(pin 1 5);
1.0A(pin 2 3 4).
Contact Resistance:50mΩ Max.
Insulation Resistance:100MΩ Min.
Dielectric Withstanding Voltage:
500 V AC For 1 Minute.
Operating Life:5000 cycles.
Operating Temperature: -20℃~+85℃

Technical Documents

Please contact us for more information.

X

X
Enlarge

Quick View

CONN PLUG MICRO USB TYPE B SMD :RHTAY36-5M2

Series Part No:RHTAY36-5M2

RoHS Compliance:Yes

Download Datasheet:

Write Your Request Full P/N :

QTY:

Features

-Compact SMD Design：Optimized for PCB surface mounting, saving space in compact electronic devices.
-High Durability：Supports thousands of insertion and removal cycles without performance loss.
-Stable Data Transmission：Ensures reliable high-speed USB data transfer and power delivery.
-Corrosion-Resistant Contacts：Gold-plated pins provide long-term reliability and prevent oxidation.

Applications

1.Consumer Devices

2.Smart Home Devices

3.Medical Devices

4.Automotive Electronics

Specifications

Material:
Housing:Hing Temperature Plastic,
UL94V-0,Black.
Contact:C2680/C5191.
Shell:Copper.
Finish:
Contact:Plated Gold In Mating Area;
Tin Lead On Solder Talls.
Shell:Nickel Plating.
Electrical:
Contact Resistance:30mΩ Max.
Insulation Resistance:100MΩ Min.

Technical Documents

Please contact us for more information.

X

X
Enlarge

Quick View

CONN PLUG MICRO USB TYPE B SMD :RHTAY36-5M3

Series Part No:RHTAY36-5M3

RoHS Compliance:Yes

Download Datasheet:

Write Your Request Full P/N :

QTY:

Features

-Corrosion-Resistant Contacts：Gold-plated pins provide long-term reliability and prevent oxidation.
-Easy PCB Soldering：Compatible with automated reflow soldering processes for efficient assembly.
-Low-Profile Form Factor：Ideal for portable electronics, wearables, and space-constrained applications.
-Wide Compatibility：Works with standard Micro USB Type B cables and devices across consumer and industrial electronics.

Applications

1.Charging Stations

2.Data Transfer Modules

3.USB Hubs

4.Test & Measurement Equipment

Specifications

Material
Housing:Hing Temperature Thermoplastics,
UL94V-0 LCP,Black.
Contact:C2680/C5191.
Shell:Copper/iron/stainless steel.
Finish:
Contact:Plated Gold In Mating Area;
Tin Lead On Solder Talls.
Shell:Tin Lead Plating.
Electrical:
Contact Resistance:30mΩ Max.
Dielectric Withstanding Voltage:
50 V AC AT Sea Level.
Insulation Resistance:100MΩ Min.

Technical Documents

Please contact us for more information.

X

X
Enlarge

Quick View

CONN PLUG MICRO USB TYPE B CLIP L6.8: RHTAY36-5M6

Series Part No:RHTAY36-5M6

RoHS Compliance:Yes

Download Datasheet:

Write Your Request Full P/N :

QTY:

Features

-Compact Clip Design：Optimized low-profile SMD clip for PCB surface mounting, ideal for space-constrained electronics.
-High Durability：Engineered to withstand thousands of insertion and removal cycles, ensuring long-term reliability.
-Stable Data Transmission：Supports high-speed USB 2.0/3.0 data transfer with consistent power delivery.
-Clip-type Secure Connection：Provides strong mechanical retention to prevent accidental disconnection in portable devices.

Applications

1.Automotive Electronics

2.Telecommunications Equipment

3.Medical Devices

4.Smart Home Devices

Specifications

Material
Housing:Hing Temperature Thermoplastic
with g.f,UL94V-0.
Contact:Copper Alloy,t=0.20mm.
Shell:SUS,t=0.20mm.
Electrical:
Current Rating:1A Max.
Dielectric Withstanding Voltage:
100 V AC for 1 min.
Contact Resistance:50mΩ Max.
Insulation Resistance:100MΩ Min.
Total Mating Force:3.57 kgf Max.
Total Unmating Force:1.0 kgf Min.
Temperature Range:
-30°C Up To +80°C

Technical Documents

Please contact us for more information.

X

X
Enlarge

Quick View

CONN PLUG MICRO USB TYPE B CLIP L8.8 : RHTAY36-5M7

Series Part No:RHTAY36-5M7

RoHS Compliance:Yes

Download Datasheet:

Write Your Request Full P/N :

QTY:

Features

-Corrosion-Resistant Contacts：Gold-plated pins resist oxidation and maintain stable electrical performance over time.
-Easy PCB Soldering：Designed for reflow soldering and automated PCB assembly processes, improving manufacturing efficiency.
-Wide Compatibility：Compatible with standard Micro USB Type B cables and a wide range of consumer and industrial electronics.
-Robust Mechanical Stability：Built to resist vibration, mechanical stress, and thermal expansion, ensuring secure connections on PCBs.

Applications

1.Wearable Technology

2.Networking Equipment

3.Robotics

4.Embedded Systems

Specifications

Housing:Hing Temperature Thermoplastic
with g.f,UL94V-0.
Contact:Copper Alloy,t=0.20mm.
Shell:SUS,t=0.20mm.
Electrical:
Current Rating:1A Max.
Dielectric Withstanding Voltage:
100 V AC for 1 min.
Contact Resistance:50mΩ Max.
Insulation Resistance:100MΩ Min.
Total Mating Force:3.57 kgf Max.
Total Unmating Force:1.0 kgf Min.
Temperature Range: -30°C Up To +80°C

Technical Documents

Please contact us for more information.

X

X
Enlarge

Quick View

CONN PLUG MICRO USB TYPE B CLIP: RHTAY36-5M8

Series Part No:RHTAY36-5M8

RoHS Compliance:Yes

Download Datasheet:

Write Your Request Full P/N :

QTY:

Features

-Corrosion-Resistant Contacts：Gold-plated pins ensure long-term reliability and prevent oxidation.
-Easy PCB Soldering：Compatible with automated reflow soldering processes for efficient assembly.
-Wide Compatibility：Works with standard Micro USB Type B cables and various consumer and industrial electronics.
-Robust Mechanical Stability：Resists mechanical stress, vibration, and thermal expansion for secure PCB connections.

Applications

1.Audio/Video Equipment

2.Security & Surveillance Devices

3.Gaming Devices

4.Energy Monitoring & Control Systems

Specifications

Material
Housing:Hing Temperature Thermoplastics,
UL94V-0 LCP,Black.
Contact:C2680/C5191.
Shell: Steel.
Finish:
Contact:Plated Gold In Mating Area;
Tin Lead On Solder Talls.
Shell:Tin Lead Plating.
Electrical:
Contact Resistance:30mΩ Max.
Dielectric Withstanding Voltage:
50 V AC AT Sea Level.
Insulation Resistance:100MΩ Min.

Technical Documents

Please contact us for more information.

X

X

Previous page 1 2 3 4
