Features
-Pin Configuration:Includes 6 primary pins for electrical connections (typically power, ground, and data signals) and 2 additional pins for features like SIM card detection (CD pin) or other specific functionalities.
-Height (H1.85mm):Specifies the vertical clearance required above the PCB surface for the connector, ensuring proper spacing for components and airflow within the electronic device.
-High Durability:Designed to withstand frequent insertion and removal cycles, ensuring long-term durability and reliable performance.
-Secure Connection:Provides a stable and secure connection to the SIM card, minimizing the risk of disconnection due to vibrations or impacts.
-Electrical Contact: Ensures secure and reliable electrical contact with the SIM card, preventing signal loss or disruption.
Applications
1.Medical Devices
2.Security Systems
3.Point of Sale (POS) Terminals
4.Industrial Automation
Specifications
SIM Card Connector,PUSH PUSH,6P+2P,H1.85mm,without Post
Material:
Insulator:H-Temperature Plastic,UL94V-0.Black.
Contact:Copper Alloy,T=0.15mm
Shell:Stainless Steel,T=0.15mm
Finsh:
Terminal:50u" min Nickel Underplated on Allover,Gold Plating on Contact Arer,80u" min Tin on Solder Tail.
Shell:50u" Nickel Underplated on Allover,Gold Flash on Solder Latch.
Electrical:
Current Rating:0.5A.
Voltage Rating:5.0 Vrms.
Insulation Resistance:500M Min.At DC 500V DC
Withstanding Voltage:250V ACrms For 1 Minute.
Contact Resistance:100M Max.At 10MA/20mV MAX.
Operating Temperature: -45ºC~+85ºC
Mating Cycles:5000 Insertions.
Technical Documents
Please contact us for more information.
